Technical parameters The company reserves the right of final interpretation for the following parameters, and subject to change without notice.



Machine model: 1630/1835/2125/2825/3216/3300/3260

Cutting range: 1600x3000mm, 1800x3500mm, 2100x2500mm, 2800x2500mm, 3200x1600mm, 3300x3300mm, 3200x6000mm

Cutting materials: knitted cloth, woven cloth, linen fiber cloth, industrial technology cloth, curtain head cloth, lace, ice silk summer mat series, home textile bed cover, quilted quilt series, etc.

Bed configuration: seamless welded steel bed/aluminum profile split combined bed

Head configuration: optional single laser head/multi-laser head

Maximum speed: 1200mm/s

Maximum thickness: ≤5mm (according to different material properties)

Material fixing: exhaust fan adsorption

Repeatability: ±0.1mm

Transmission system: domestic servo motor, linear silent guide rail, synchronous belt

Machine power: 3KV/5KV

Rated voltage: AC220V±10%

Data format: PLT, DXF, AI, PDF, DST, HPGL

Control center: microcomputer multi-function advanced LCD touch screen

Data transmission: Ethernet

Positioning method: optical projection/digital camera/industrial camera scanning/red light cross
